Paige 459156, 2 Pair 18 AWG Stranded Tinned Copper, Unshielded, Roll of 305 MTR

 CABLE CONSTRUCTION

 1. Conductors

 1.1 Material: Tinned Copper
 1.2 Size: 18 AWG
 1.3 Construction: 16 Strands

 2. Insulation

 2.1 Material: PVC
 2.2 Wall Thickness: .013”
 2.3 Color code:
          1-Black x Red
          2-Black x White

 3. Cabling Overall Lay

 3.1 4” left hand lay

 4. Jacket

 4.1 Material: Sunlight Resistant PVC
 4.2 Wall Thickness: .032”
 4.3 OD: .333” nom.
 4.4 Color: Gray
 4.5 Ripcord under jacket
 4.6 Markings: PAIGE #459156 18 AWG 2 PAIR (UL) CL3 OR c(UL)us CMG FT4 OR AWM
       STYLE 2464 80C 300V E191597 MADE IN USA ROHS
       (Ascending/Descending footage markings)

 5. Electricals

 5.1 Capacitance: 25.5 pF/ft.
 5.2 DC Resistance: 5.86 ohms/M ft.
 5.3 Voltage: 300 Volts

 Scope:
 This cable consists of 2 pairs 18 AWG stranded tinned copper; color-coded
 PVC insulation; sunlight resistant overall PVC jacket.
 RoHS Compliant
