Paige 454681AGR 20AWG-3C Stranded, Shielded, PVC Cable

 CABLE CONSTRUCTION

 1. Conductors

 1.1 Material: Bare Copper
 1.2 Size: 20 AWG
 1.3 Construction: 7 Strand

 2. Insulation

 2.1 Material: PVC
 2.2 Wall Thickness: .008"
 2.3 Color code: Black, White, Red

 3. Cabling Overall Lay

 3.1 21⁄2" left hand lay

 4. Shield

 4.1 Material: Aluminum Mylar Foil

 5. Drain

 5.1 Material: Tinned Copper 2.5.2 Size: 24 AWG
 5.3 Construction: 7 Strand

 6. Jacket

 6.1 Material: PVC
 6.2 Wall Thickness: .015"
 6.3 OD:.146" nom. 2.6.4 Color: Gray
 6.5 Rip Cord: Yes
 6.6 Markings: PAIGE #454681 AGR 20AWG 3C SHIELDED (UL) TYPE CL3R/FPLR OR
       c(UL)us CMR E191597 ROHS MADE IN USA (Ascending / Descending footage markings)

 7. Electricals

 7.1 Capacitance: 55 pf/ft.
 7.2 DC Resistance: 10.3 ohms/M ft.
 7.3 Voltage: 300 Volts

 Scope

 This cable consists of 3 conductors 20 AWG stranded bare copper; color-coded PVC insulation;

 overall aluminum mylar foil shield with drain wire; overall PVC jacket.

 RoHS Compliant
