Hioki AC/DC Clamp Meters



    AC CLAMP METER

    Hioki clamp meters are best-in-class measuring devices incorporating Hioki’ s expertise in current sensing technology. The CM3289 is a True RMS rectifying 1000A AC clamp                meter that  features abroad operating  temperature range of -25° C to 65° C, thin and compact clamp core and optional flexible current sensor that you can attach to let you get        into the tightest spots.


   Key Features

   New redesigned sensor for even easier clamping
   The CM3289 is the successor to the popular 3280-20F with a redesigned thinner sensor to help you get into the tightest spaces.
   Expanded -25 °C to 65 °C operating temperature range
   Measure even harmonic waveform components using the True RMS method
   Connect the CT6280 flexible sensor to measure up to 4199 A in thick or paired wires

  Resistance range

    420.0 Ω to 42.00 MΩ, 6 ranges, Basic accuracy: ±2 % rdg. ±4 dgt.

  Other functions

    Continuity: Buzzer sounds at 50 Ω ±40 Ω or less, Data hold, Auto power save, Drop-proof from height of 1 meter

 Typical applications are:

       Clamp meters are highly efficient at safely and speedily measuring current, without interrupting the current flow or using test leads. The clamps measure current such as AC               current, AC and DC voltage, resistance, and continuity. Some models can also measure DC current, capacitance, temperature, and frequency
