Hager RCBO 1 Pole, 20AMP, 30MA, 6KA, AD120Z

  HAGER RCBO

   Characteristics

    Compact protection devices which combine the  overcurrent functions of an MCB with the earth fault functions of  an RCCB in a single unit.
    These devices are single pole & solid neutral.

   Technical Data

    - tripping curve:
        C curve: 5 to 10 In
    - sensitivity:
        high sensitivity: 10mA, 30mA
        medium sensitivity: 100mA, 300mA
    - voltage: 230V AC
    - current: 6A to 40A
    - frequency: 50Hz / 60Hz
    - type: AC type (Ensured for residual sinusoidal alternating currents, whether suddenly applied or slowly rising)

   Technical Features

     - bi-connect (cable & busbar)
     - flying neutral lead length: 700mm
     - will not accept auxiliaries
     - poles: SP & passing N
     - climate sealed: T2
     - trip free mechanism
     - fixed instantaneous tripping

   Connection Capacity

    - flexible: up to 16 mm2
    - rigid: up to 25 mm2

 Typical applications are:

 RCBOs are commonly used in applications where there is the need to combine protection against overcurrents (overload and short-circuit) and protection against   Earth leakage currents.
